3-Phase Energy Meter

3-Phase Energy Meter Supports Wye/Delta up to 600VAC.

For USA/Canada 60Hz electrical panels.

  • Eyedro's 3-Phase Energy Meter empowers you with real-time electricity usage data via MyEyedro cloud, or use in local mode.
  • Measure amperage, voltage, power factor, wattage (true-power), watt-hours.
  • Use amperage sensors rated for your application. Available up to 3000A (contact Eyedro Sales for amperages up to 6000A).
  • Directional amperage sensors open for easy installation around circuit being measured.
  • Voltage measured via power adapter (outside panel).
  • Requires a WiFi or Ethernet connection to use MyEyedro.
  • Full details below. Contact Eyedro Sales for more information.

Real-Time Energy Monitoring for Commercial/Industrial.

Why wait for your utility bill to arrive to find out how much you’ve consumed – with Eyedro’s electricity monitors you can see, in real-time, your electricity usage. Eyedro provides timely and actionable insights that allow you to stay on top of your electricity spend, making your electricity usage easy to understand. Eyedro business electricity monitors provide an easy and affordable way for business owners and facility managers to monitor and track energy usage in real time, taking the surprise out of your utility bill.



Use Eyedro to:

  • Monitor your electricity consumption and stay on budget.
  • Understand utility bills and measure improvements.
  • Discover phantom power drains or peak power demand.
  • Uncover your energy habits.
  • LANDLORDS: monitor your tenants’ electricity usage, create custom reports, and share real-time data with your tenants!


MyEyedro Cloud Service

Eyedro and MyEyedro are always working together to measure, analyze and store your electricity usage and cost information. With MyEyedro, your electricity data is automatically and securely stored in the cloud, so it’s ready when and where you need it most. MyEyedro presents your electricity data in ways that are engaging, informative and easy to understand. See real-time electricity usage and gain access to many helpful features, including:

  • Responsive real-time graphs
  • Hourly/Daily/Weekly/Monthly cost estimates
  • Bill comparisons and estimates


DISCOVER HOW MUCH MONEY YOUR ELECTRICITY IS COSTING YOU IN REAL-TIME:  see your usage change as you turn your devices on and off.

  • ACCESS YOUR INFO ON-THE-GO WITH YOUR PHONE, TABLET, OR COMPUTER:  no software to download.
  • DIRECTIONAL SENSING, SOLAR READY: Can identify power consumed vs. power generated.
  • CUSTOMIZABLE RATE SETTINGS:  input your electricity rates to match your utility, match your bills to your MyEyedro report.
  • VIEW YOUR USAGE DATA IN Wh, $, A, V, PF, W (TRUE POWER):  MyEyedro is powerful cloud-based software that is included with your Eyedro hardware with no subscription fee.
  • ARE YOU A LANDLORD OR OWN A RENTAL UNIT?  You can track your tenants’ electricity usage, create custom reports and even share real-time usage information with your tenants


The Eyedro WiFi/Ethernet 3-phase energy meter is perfect for monitoring electricity consumption or generation in any business (up to 3000A/600V).

European 50Hz models available. Contact Eyedro Sales.



Getting Started 1 – Connect Your Eyedro to Your WiFi Network (skip if connecting by Ethernet)



Eyedro WiFi Setup



Getting Started 2 – Install Eyedro Hardware



Installing Eyedro Current Sensors

Installing Eyedro Modules

Eyedro Business Products Guide



Getting Started 3 – MyEyedro Cloud Software



Add Your Eyedro to Your MyEyedro Account

MyEyedro Cloud Overview Video Tutorial

MyEyedro User Guide

Additional Information

Additional information

Weight 1 kg
Dimensions 26 × 20 × 10 cm
Connectivity

WiFi (2.4 GHz) or Ethernet

Application

For measuring a 3-phase Wye or Delta 100-600VAC 60Hz electrical circuit up to 3000A (depending on amperage sensors used).

Measures

watt-hours, watts, amps, volts, power factor. Sensors are directional.
